CSF Radiator for BMW F20-F21 1 Series - Manual

CSF Radiator for BMW F20/F21 1 Series - Manual

Fits:

• F20/F21 1 Series
• F22/F23 2 Series
• F30/F31 3 Series
• F32/F33 4 Series
• F34 3 Series Gran Coupe
• F36 4 Series Gran Coupe
• I3

Year	Model	Sub-Model	Chassis Code	Engine Code
10-18	118i	5 doors	F20	B13
10-18	120d	5 doors	F20	N47N
10-15	125d	5 doors	F20	N47S1
10-18	125i	5 doors	F20	N20
10-18	M135i	5 doors	F20	N55
14-18	116i	5 doors	F20	B38
10-18	118i	3 doors	F21	N13
10-15	125d	3 doors	F21	N47S1
10-18	125i	3 doors	F21	N20
10-18	M135i	3 doors	F21	N55
14-18	116i	3 doors	F21	B38
14-18	120d	3 doors	F21	B47
14-18	120i	3 doors	F21	N13
12-17	218i	Coupe	F22	B38
12-17	220d	Coupe	F22	B47
12-17	220i	Coupe	F22	N20
12-17	228i	Coupe	F22	N20
14-17	218i	Convertible	F23	B38
14-17	220d	Convertible	F23	B47
14-17	220i	Convertible	F23	N20
14-17	228i	Convertible	F23	N20
11-16	316d	Sedan	F30	N47N
11-18	318d	Sedan	F30	N47N
11-18	320d(X)	Sedan	F30	N47N
11-18	320i(X)	Sedan	F30	N20
11-18	325d	Sedan	F30	N47S1
11-18	328i(X)	Sedan	F30	N20
11-16	335i(X)	Sedan	F30	N55
14-18	318i	Sedan	F30	B38
11-15	316d	Touring	F31	N47N
11-15	318d	Touring	F31	N47N
11-18	320d(X)	Touring	F31	N47N
11-15	320i(X)	Touring	F31	N20
11-18	325d	Touring	F31	N47S1
11-15	328i(X)	Touring	F31	N20
11-15	335i	Touring	F31	N55
14-18	318i	Touring	F31	B38
12-16	318d	Gran Turismo	F34 GT	N47N
12-16	320d(X)	Gran Turismo	F34 GT	B47
12-16	320i(X)	Gran Turismo	F34 GT	N20
12-16	325d	Gran Turismo	F34 GT	N47S1
12-17	420d(X)	Coupe	F32	N47N
12-17	420i(X)	Coupe	F32	N20
12-17	425d	Coupe	F32	B47
12-17	428i(X)	Coupe	F32	N20
12-17	435i(X)	Coupe	F32	N55
13-17	420d	Convertible	F33	B47
13-17	420i	Convertible	F33	N20
13-17	425d	Convertible	F33	N47S1
13-17	428i	Convertible	F33	N20
13-17	435i(X)	Convertible	F33	N55
13-17	418i	Gran Coupe	F36 Gran Coupe	B38
13-17	420d(X)	Gran Coupe	F36 Gran Coupe	B47
13-17	420i(X)	Gran Coupe	F36 Gran Coupe	N20
13-17	425d	Gran Coupe	F36 Gran Coupe	B47
13-17	428i(X)	Gran Coupe	F36 Gran Coupe	N20
13-17	435i(X)	Gran Coupe	F36 Gran Coupe	N55
13-17	i3	60aH Rex	i3	IB1

CSF manufactures the most advanced and efficient radiator cores in the industry by using innovative tube and fin technologies with industry leading testing methods to maximise airflow and heat dissipation. These techniques allow CSF to stay ahead of the pack when it comes to radiator technology!

• “B-Tube” technology – Unlike a regular oval shape “O” type radiator tube, CSF uses a specially engineered tube in a shape of a “B”. These “B-tubes” are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminium material (better cooling efficiency) because this design is actually stronger than normal “O” shape tubes that are welded.

• The design (inlet in the middle of tube that is seam brazed) increases the heat transfer surface area of the tubes by approximately 15% over regular tubes. You get the efficiency of 2 smaller tubes vs. 1 large tube within the same space criteria. With “B-tubes” you are able to get “dual liquid laminar flow.”

• High Efficiency Multi Louvered Fin – CSF uses ultra efficient multi louvered fins that are carefully and precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in our wind-tunnel lab.
