CSF Race Radiator for E9X 3 Series

CSF Race Radiator for E9X 3 Series

Fits:

04-11	316i	Sedan	E90	N43
07-11	316i	Sedan	E90	N45N
04-11	318i	Sedan	E90	N43
04-11	318i	Sedan	E90	N46
04-11	318i	Sedan	E90	N46N
04-11	320i	Sedan	E90	N43
04-08	320i	Sedan	E90	N46
04-11	320i	Sedan	E90	N46N
04-08	320si	Sedan	E90	N45
04-08	323i	Sedan	E90	N52
04-11	323i	Sedan	E90	N52N
04-08	325i	Sedan	E90	N52
04-11	325i	Sedan	E90	N52N
04-11	325i	Sedan	E90	N53
04-08	325xi	Sedan	E90	N52
04-11	325xi	Sedan	E90	N52N
04-11	325xi	Sedan	E90	N53
04-11	328i	Sedan	E90	N52N
04-11	328xi	Sedan	E90	N52N
04-08	330i	Sedan	E90	N52
04-11	330i	Sedan	E90	N52N
04-11	330i	Sedan	E90	N53
04-11	330xi	Sedan	E90	N52
04-11	330xi	Sedan	E90	N53
07-12	316i	Touring	E91	N43
04-12	318i	Touring	E91	N43
04-08	318i	Touring	E91	N46
04-12	318i	Touring	E91	N46N
04-12	320i	Touring	E91	N43
04-08	320i	Touring	E91	N46
04-12	320i	Touring	E91	N46N
04-08	323i	Touring	E91	N52
04-12	323i	Touring	E91	N52N
04-08	325i	Touring	E91	N52
04-12	325i	Touring	E91	N52N
04-12	325i	Touring	E91	N53
04-08	325xi	Touring	E91	N52
04-12	325xi	Touring	E91	N52N
04-12	325xi	Touring	E91	N53
04-12	328i	Touring	E91	N52N
04-12	328xi	Touring	E91	N52N
04-08	330i	Touring	E91	N52
04-12	330i	Touring	E91	N52N
04-12	330i	Touring	E91	N53
04-08	330xi	Touring	E91	N52
04-12	330xi	Touring	E91	N53
05-13	316i	Coupe	E92	N43
08-13	318i	Coupe	E92	N43
05-13	320i	Coupe	E92	N43
05-13	320i	Coupe	E92	N46N
05-13	323i	Coupe	E92	N52N
05-13	325i	Coupe	E92	N52N
05-13	325i	Coupe	E92	N53
05-13	325xi	Coupe	E92	N52N
05-13	325xi	Coupe	E92	N53
05-13	328i	Coupe	E92	N52N
05-13	328xi	Coupe	E92	N52N
05-13	330i	Coupe	E92	N52N
05-13	330i	Coupe	E92	N53
05-10	330xi	Coupe	E92	N52N
05-13	330xi	Coupe	E92	N53
09-13	318i	Convertible	E93	N43
05-13	320i	Convertible	E93	N43
05-13	320i	Convertible	E93	N46N
05-13	323i	Convertible	E93	N52N
05-13	325i	Convertible	E93	N52N
05-13	325i	Convertible	E93	N53
05-13	328i	Convertible	E93	N52N
05-13	330i	Convertible	E93	N52N
05-13	330i	Convertible	E93	N53

CSF manufactures the most advanced and efficient radiator cores in the industry by using innovative tube and fin technologies with industry leading testing methods to maximise airflow and heat dissipation. These techniques allow CSF to stay ahead of the pack when it comes to radiator technology!

• “B-Tube” technology – Unlike a regular oval shape “O” type radiator tube, CSF uses a specially engineered tube in a shape of a “B”. These “B-tubes” are carefully formed and then brazed over the seam to seal. CSF is able to use thinner and lighter aluminium material (better cooling efficiency) because this design is actually stronger than normal “O” shape tubes that are welded.

• The design (inlet in the middle of tube that is seam brazed) increases the heat transfer surface area of the tubes by approximately 15% over regular tubes. You get the efficiency of 2 smaller tubes vs. 1 large tube within the same space criteria. With “B-tubes” you are able to get “dual liquid laminar flow.”

• High Efficiency Multi Louvered Fin – CSF uses ultra efficient multi louvered fins that are carefully and precisely aligned to maximize airflow through each radiator core. Fin specifications are carefully measured and calculated for each application, and tested for maximum heat rejection efficiency in our wind-tunnel lab.
